TrolMaster Hydro-X Dry Contact Station Single Pack with Cable Set

TrolMaster Hydro-X Dry Contact Station Single Pack with Cable Set

  • $68.00
Shipping calculated at checkout.

Call To Order - (330) 758-0272

The Trolmaster DSD-1 Dry-contact module provides a simple and flexible solution to user’s who want to connect & control devices to the Hydro-X using a dry-contact or relay to activate the device. Some equipment requires either normally open or normally closed contact closure in order to activate the equipment. The DSD-1 is the product that you need to control those types of devices.*

The DSD-1 plugs into a standard Nema 120 volt 15/20-amp power outlet to provide operating power to the DSD-1 circuitry. Then the user can use any voltage (up to 240 volts @ 10-amps) to connect their control voltage from their equipment to the common, normally open and/or normally closed contacts on the DSD-1. Almost any device that requires a dry-contact or relay to activate will work with the DSD-1.

The DSD-1 can be configured to work as the other Trolmaster power modules work. The DSD-1 connects into the devices line on the Hydro-X and can be set to control an almost infinite number and types of devices such as: Lighting contactors,Light Deprivation curtains,Pump contactors,Temperature devices,Humidity devices,CO2 devices

* Consult Trolmaster for questions concerning your particular device.
